7 Save/Recall/Print
7.2 Recall
<integer>
Memory used
<integer>
Memory free
<integer>
File count in ARB memory
<string>,<string>, …
<string>
Comma-separated string list of waveform segments within
ARB memory
Example:
:SOUR:RAD:ARB:FCAT?
EXT returns: 27499,2069653,3,”c2k.wfm”,”gsm.wfm”,”wcdma.wfm”
7.2.15 Power Sensor Cal Factor
Selects a file to which to export the Power Sensor Cal factor data.
Cal Factor files are XML files, and contain the cal factor data and header data that
gives information on the power sensor.
The default path for Cal Factor Files is:
My Documents\<mode name>\data\PSCF
where <mode name> is the parameter used to select the mode with :INST:SEL (for
example, MRECEIVE for Measuring Receiver Mode). Hence, a Cal Factor file from any
measurement in the Measuring Receiver mode would be stored in:
My Documents\MRECEIVE\data\PSCF
Cal Factor files have the extension .xml. The default filename is <Sensor Model>_
<Sensor Serial Number>_0000.xml, where the 4-digit number is the lowest
number that does not conflict with any filename in the current directory. If the
sensor model or serial number is blank, the default filename is PSCF_0000.xml.
Remote Command
:MMEMory:STORe:PSCFactor <file_name>
Example
:MMEM:STOR:PSCF "myPSCF.xml"
Notes If the save is initiated via SCPI, and the file already exists, the file will be overwritten
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade
Both single and double quotes are supported for any filename parameter over SCPI
Dependencies Only appears if you have the proper option installed in your instrument
7.2.16 Loss Comp
Sets the import file type to Loss Compensation Before DUT Table or to Loss
Compensation After DUT Table.
Spectrum Analyzer Mode User's &Programmer's Reference 2550
