Keysight x-series User Manual

6 Input/Output
6.1 RF Source
Power <ampl> - specifies the output power for the step in dBm. For details of the valid ranges, see
"Power" on page 2248
If input parameter number exceeds the step number defined by "Number of Steps" on page 2239,
then error -221, "Settings conflict; The number of input parameters is too large and is truncated to
current list step number" is generated, and only those parameters whose index number falls within
legal step number will be updated
Dependencies The range is 1 to 1000, which is determined by the number of steps you have configured. For details
see "Number of Steps" on page 2239
Step Configuration of Waveform parameter list (Remote Command Only)
Configures the Waveform parameter array of the whole List Sequencer at one time.
The number of arrays is same as step number defined in "Number of Steps" on page
2239. As a step is set up, the value entered runs through several levels of validation.
Remote Command
:SOURce:LIST:SETup:WAVeform <string>, <string>, <string>, …
:SOURce:LIST:SETup:WAVeform?
Example
:SOUR:LIST:SET:WAV "CW","Off","CONT"
:SOUR:LIST:SET:WAV?
Notes Sets up or queries the parameter array of whole list sequence
Waveform <string> - specifies the waveform for playback during the step. The step can output either a
new ARB waveform, continue playback of the previous waveform, or output a CW tone. The options for
specifying these are:
<filename>
Plays the specified waveform from the start. The filename value is the name
of the file within ARB playback memory, it is does not include the windows
path to the file on the HDD. If you enter a filename for a waveform that does
not reside within ARB playback memory, an error is generated
CONT
Continues playback of the ARB file from the previous step
CW
Outputs a CW tone
OFF
Disables the RF output
If input parameter number exceeds the step number defined by "Number of Steps" on page 2239,
then error -221, "Settings conflict; The number of input parameters is too large and is truncated to
current list step number" is generated, and only those parameters whose index number falls within
number of steps will be updated
Dependencies The range is 1 to 1000 which is determined by the number of steps you have configured. For details
see "Number of Steps" on page 2239
Range
"filename" | "CW" | "Off" | "CONT"
2258 Spectrum Analyzer Mode User's &Programmer's Reference
