8 Trigger
8.1 Trigger
State Saved Yes
Range
NORMal|MJITter
Options
Trigger optimization options are:
Trigger
Optimization
SCPI Notes
Normal
NORMal
No optimization
Minimum Jitter
MJITter
Optimizes trigger for minimum jitter. A software resample
method is provided to reduce jitter, at the expense of some
measurement speed
The acquisition jitter depends on the digital IF BW, the jitter
will be smaller when digital IF BW gets larger. For example,
when the digital IF BW is 98.3 MHz in 5GNR, the jitter varies
under 15ns. When set MJITter as trigger optimization type,
the jitter will be reduced to 1ns
This setting apples to all the Trigger Sources
8.1.23 Trigger Settings Diagram
Lets you configure the Trigger system using a visual utility.
First, select what you want to configure (the Trigger, Gate or Periodic Sync Source)
by tapping the box for Trigger, Gate or Periodic Sync Source.
Next, tap any box in the gray row to choose a Trigger Source to connect to. For
Periodic Sync Source, you can also tap Off.
The Trigger Settings Diagram changes depending on context. The Trigger Sources
that are available change depending on which input you have selected.
2681 Spectrum Analyzer Mode User's &Programmer's Reference
