3 Spectrum Analyzer Mode
3.8 Spurious Emissions Measurement
3.8.10.5 Advanced
Contains controls for setting advanced trace functions of the instrument.
Measure Trace
Specifies which trace’s scalar results are displayed in the Metrics window, and
retrieved by sending a :READ or :FETCh query:
–
Trace 1
–
Trace 2
–
Trace 3
Remote Command
:CALCulate:<meas>:MTRace TRACe1 | TRACe2 | TRACe3
:CALCulate:<meas>:MTRace?
<meas> is the identifier for the current measurement; any one of CHPower | ACPower |
OBWidth | SEMask | SPURious | PVTime
Example Channel Power
:CALC:CHP:MTR TRAC1
:CALC:CHP:MTR?
Dependencies In the ACP measurement, this control is grayed-out when Meas Method is set to RBW or FAST, and
only Trace 1 is enabled
Preset
TRACe1
State Saved No
Range Trace 1 | Trace 2 | Trace 3
1526 Spectrum Analyzer Mode User's &Programmer's Reference
