Keysight x-series User Manual

6 Input/Output
6.8 Trigger Output
Dependencies You can only send TRIG parameters for the hardware you have; for example, you cannot send a
TRIG3 parameter if your hardware does not support TRIG3. Sending the command for an output you
do not have generates an error, “Hardware missing; Not available for this model number”
Querying a non-existent output returns OFF
Trig 2 Out Polarity does not appear in EXM or VXT
Preset Unaffected by Preset, but set to POSitive by Restore Input/Output Defaults or Restore System
Defaults->All
State Saved Saved in instrument state
6.8.3 Trig 1 – 4 Out Device
Sets the output to the Trig n Out connector to trigger on either ANALyzer or
SOURce.
Remote Command
:TRIGger[1]|2|…|4[:SEQuence]:OUTPut:DIRection ANALyzer | SOURce
:TRIGger[1]|2|…|4[:SEQuence]:OUTPut:DIRection?
Example
:TRIG1:OUTP:DIR ANAL
Dependencies Only available on VXT models M9410A/11A/15A/16A and M9410E/11E/15E/16E
Preset Unaffected by Preset
Restore Input/Output Defaults and Restore System Defaults->All preset the triggers as follows:
Trig n Out Device Preset
1, 3, 4
ANALyzer
2
SOURce
State Saved Saved in instrument state
6.8.4 Src PXI Trig Out
Selects which signal will be routed to the backplane Source PXI Trigger Output Line.
Remote Command
:TRIGger:PXIE:SOURce[:SEQuence]:OUTPut S1Marker | S2Marker | S3Marker |
S4Marker | PARB | OFF
See "Option details" on page 2478
:TRIGger:PXIE:SOURce[:SEQuence]:OUTPut?
Example
:TRIG:PXIE:SOUR:OUTP S1M
:TRIG:PXIE:SOUR:OUTP?
Dependencies Only appears in EXM, VXT and M941xE
Preset
OFF
State Saved Saved in instrument state
Spectrum Analyzer Mode User's &Programmer's Reference 2477
