3 Spectrum Analyzer Mode

3.9 SEM Measurement

Offset/Limits Config Table

This function is the same as "Offset/Limits Config Table" on page 1624 under the

"Settings" on page 1620 tab.

Sets the power reference in the carrier that will be used to compute the relative

values for the offsets.

3.9.18.4 Meas Standard

Contains controls that allow you to preset the PowerSuite measurements to

conform to various communications standards.

Radio Standard Presets

Lets you specify the Radio Standard to be used. Spectrum Analyzer Mode supports

many Radio Standards. You can select the desired Radio Standard using the Radio

Std Presets dialog, which is a cascading list of standards. When you have the

selected the desired Standard, press OK and the measurement settings will change

to reflect that standard.

Remote Command

[:SENSe]:RADio:STANdard[:SELect] NONE | JSTD | IS95a | IS97D | IS98D | GSM

WL11AY4G32 | WL11AY6G48 | WL11AY8G64 | NR5GFR1B100M

[:SENSe]:RADio:STANdard[:SELect]?

Example

:RAD:STAN NONE

:RAD:STAN?

Dependencies Some selections appear only when support license is valid

Couplings By changing the radio standard, the measurement parameters will be automatically set to an

appropriate default value

State Saved Saved in instrument state

The Radio column in the table lets you specify the device to be used. It is a global

setting that affects the Device selection, between Mobile (MS) and Base Station

(BTS) settings, for all relevant PowerSuite measurements. The Device SCPI

command has the same effect as a selection in the Radio column:

Remote

Command

[:SENSe]:RADio:STANdard:DEVice BTS | MS

[:SENSe]:RADio:STANdard:DEVice?

Spectrum Analyzer Mode User's &Programmer's Reference 1703
