Keysight x-series User Manual

6 Input/Output
6.1 RF Source
VXT models
M9415A/16A
No-Across chassis MIMO is supported when license M941xA-MMO is
enabled
Range
NONE|TWO|THRee|FOUR|SIX|EIGHt|DONE|DTWO|DTHR|DFOU
Option Details
Parameter SCPI Notes
None
NONE
Sets MIMO Config type as None
2x2
TWO
Sets 2x2 as MIMO Config Type. 2 models are configured to Sync
3x3
THRee
Sets 3x3 as MIMO Config Type. 3 models are configured to Sync
4x4
FOUR
Sets 4x4 as MIMO Config Type. 4 models are configured to Sync
6x6
SIX
Sets 6x6 as MIMO Config Type. 6 models are configured to Sync
8x8
EIGHt
Sets 8x8 as MIMO Config Type. 8 models are configured to Sync
1x1+1x1
DONE
Sets 1x1+1x1 as MIMO Config Type. 2 models are configured to Sync with different center
frequency. Use Segment 2 Setup to config the second model
2x2+2x2
DTWO
Sets 2x2+2x2 as MIMO Config Type. 2 groups of 2x2 MIMO. First group consists of
Primary and TRX1. Second group consists of TRX2 and TRX3. Segment 2 Setup allows
you to config the second group
3x3+3x3
DTHR
Sets 3x3+3x3 as MIMO Config Type. 2 groups of 3x3 MIMO. First group consists of
Primary, TRX1 and TRX2. Second group consists of TRX3, TRX4 and TRX5. Segment 2
Setup allows you to config the second group
4x4+4x4
DFOU
Sets 4x4+4x4 as MIMO Config Type. 2 groups of 4x4 MIMO. First group consists of
Primary, TRX1, TRX2 and TRX3. Second group consists of TRX4, TRX5, TRX6 and TRX7.
Segment 2 Setup allows you to config the second group
6.1.13.2 Sync Type
Grayed-out when models are in Sync State.
Remote Command
:SOURce:SYNC:TYPE PRIMary | SECondary | OFF
For details of parameter options, see "Options" on page 2325
:SOURce:SYNC:TYPE?
Example
:SOUR:SYNC:TYPE PRIM
Preset
OFF
Range
PRIMary|SECondary|OFF
2324 Spectrum Analyzer Mode User's &Programmer's Reference
