Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.9 SEM Measurement
Stop Freq
Specifies the stop frequency for the currently selected offset.
When sending the remote command, missing values are not permitted; that is, if you
want to change values 2 and 6, you must send all values up to 6. Subsequent values
will remain unchanged. The query for this parameter returns 14 values for WLAN
mode, 12 values for other modes.
Remote
Command
[:SENSe]:SEMask:OFFSet[1]|2[:OUTer]:LIST:FREQuency:STOP <freq>, …
[:SENSe]:SEMask:OFFSet[1]|2[:OUTer]:LIST:FREQuency:STOP?
Example
:SEM:OFFS:LIST:FREQ:STOP 2.715 MHz, 3.515 MHz, 4.00 MHz, 8.00 MHz, 12.50 MHz,
15.0 MHz
:SEM:OFFS:LIST:FREQ:STOP?
Notes Comma separated list of values
OFFSet1 is for BTS, 2 for MS. Default is BTS
Note that Offset sub op code 2 is supported only in non-SA Modes. In SA Mode, Offset sub op code 1 is
used for both BTS and MS
If the offset is outside of the frequency range, the result spectrum will be invalid
Couplings Coupled to Start Freq. When Stop Freq goes below Start Freq, Start Freq is automatically adjusted to
Stop Freq minus 100 Hz
Preset When the max number of offsets is 6:
Mode Values
SA 2.715 MHz, 3.515 MHz, 4.00 MHz, 8.00 MHz, 12.50 MHz, 15.0 MHz
WCDMA 2.715 MHz, 3.515 MHz, 4.000 MHz, 8.000 MHz, 12.50 MHz, 15.0 MHz|3.485
MHz, 7.500 MHz, 8.500 MHz, 12.00 MHz, 15.00 MHz, 18.0 MHz
When the max number of offsets is 12 in these modes, the preset value of Offset G ~ L is the same as
the Offset F value
Mode Values
MSR 215 kHz, 1.015 MHz, 1.5 MHz, 10.5 MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz, 50
MHz, 50 MHz, 50 MHz, 50 MHz|215 kHz, 1.015 MHz, 1.5 MHz, 10.5 MHz, 50
MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz, 50 MHz
LTEAFDD,
LTEATDD
5.05 MHz, 10.05 MHz, 15 MHz, 30 MHz, 40 MHz, 50 MHz, 50 MHz, 50 MHz, 50
MHz, 50 MHz, 50 MHz, 50 MHz | 985.0 kHz, 4.50 MHz, 5.5001 MHz, 9.50 MHz,
20 MHz, 40 MHz, 40 MHz, 40 MHz, 40 MHz, 40 MHz, 40 MHz, 40 MHz
5G NR 5.05 MHz, 10.05 MHz, 40 MHz, 100 MHz, 500 MHz, 500 MHz, 500 MHz, 500
MHz, 500 MHz, 500 MHz, 500 MHz, 500 MHz | 985.0 kHz, 4.50 MHz, 99.500
MHz, 104.5 MHz, 500 MHz, 500 MHz, 500 MHz, 500 MHz, 500 MHz, 500 MHz,
500 MHz, 500 MHz
When the max number of offsets is 14 in these modes, the preset value of Offset G ~ N is the same as
Spectrum Analyzer Mode User's &Programmer's Reference 1635
