Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.13 Phase and Amplitude vs Time Measurement
:DISP:PAVT:VIEW:WIND:TRAC:Y:PHAS:PDIV?
Preset Automatically calculated
State Saved Saved in instrument state
Range 1 to 100
Min 1
Max 100
Annotation <value> / left upper of graph
Ref Position
Positions the reference level at the top, center or bottom of the Y Scale display.
Amplitude Scale
Positions the Amplitude scale reference level at the top, center or bottom of the Y
Scale display. Changing the reference position does not change the value of "Ref
Value" on page 1951.
Remote
Command
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:AMPLitude:RPOSition TOP |
CENTer | BOTTom
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:AMPLitude:RPOSition?
Example
:DISP:PAVT:VIEW:WIND:TRAC:Y:AMPL:RPOS TOP
:DISP:PAVT:VIEW:WIND:TRAC:Y:AMPL:RPOS?
Preset
CENTer
State Saved Saved in instrument state
Range Top|Center|Bottom
Annotation > and < are displayed both side of graph to indicate Reference Position
Phase Scale
Positions the Phase Scale reference level at the top, center or bottom of the Y Scale
display. Changing the reference position does not change the value of "Ref Value"
on page 1951.
Remote
Command
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PHASe:RPOSition TOP |
CENTer | BOTTom
:DISPlay:PAVTime:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PHASe:RPOSition?
Example
:DISP:PAVT:VIEW:WIND:TRAC:Y:PHAS:RPOS TOP
:DISP:PAVT:VIEW:WIND:TRAC:Y:PHAS:RPOS?
Preset
CENTer
Spectrum Analyzer Mode User's &Programmer's Reference 1953

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
