Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.6 Power Stat CCDF Measurement
Remote
Command
:CALCulate:PSTatistic:MARKer[1]|2|…|12:Y?
Example
:CALC:PST:MARK11:Y?
Notes Returns the marker Y-Axis result, if the control mode is Normal, or Delta. If the marker is Off, the
response is Not a Number
Preset 0
State Saved No
Backwards
Compatibility
SCPI
:CALCulate:PSTatistic:MARKer[1]|2|…|12:FUNCtion:RESult?
Marker Mode
Sets the marker control mode to Normal (POSition), Delta, or Off. All interactions
and dependencies detailed under the control description are enforced when the
remote command is sent. If the selected marker is Off, pressing Marker sets it to
Normal and places it at the center of the screen on the trace determined by the
Marker Trace rules. At the same time, Marker X Axis Value appears on the Active
Function area.
The default active function is the active function for the currently selected marker
control mode. If the current control mode is OFF, there is no active function, and the
active function is turned off.
Remote
Command
:CALCulate:PSTatistic:MARKer[1]|2|…|12:MODE POSition | DELTa | OFF
:CALCulate:PSTatistic:MARKer[1]|2|…|12:MODE?
Example
:CALC:PST:MARK:MODE POS
:CALC:PST:MARK:MODE?
Preset
OFF
State Saved Saved in instrument state
Range
POSition|DELTa|OFF
Annotation Mkr # <X value> and <Marker value> upper right on graph
When Marker Trace is Polar in WCDMA mode:
Mkr # <Chip Value (RHO & QPSKEVM)/Symbol Value (CDP)>, <X value> and <Y value> upper right on
graph
Backwards Compatibility SCPI Commands
Sets or queries the state of a marker. Setting a marker that is OFF to ON (1) puts it
into Normal mode and places it at the center of the screen.
1202 Spectrum Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
