3 Spectrum Analyzer Mode
3.5 ACP Measurement
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:LIST:STAT 1,1,0,0,0,0
:ACP:OFFS2:LIST:STAT?
Preset When "Max Num of Offsets" on page 1010 is 12, the preset value of Offset G ~ L is the same as the
Offset F value
Modes Values
SA
ON, OFF, OFF, OFF, OFF, OFF | ON, OFF, OFF, OFF,
OFF, OFF
WCDMA
ON, ON, OFF, OFF, OFF, OFF | ON, ON, OFF, OFF, OFF,
OFF
LTEAFDD, LTEATDD,
MSR
ON, ON, OFF, OFF, OFF, OFF | ON, OFF, OFF, OFF, OFF,
OFF
5G NR
ON, ON, OFF, OFF, OFF, OFF | ON, OFF, OFF, OFF, OFF,
OFF
Radio Test
ON, ON, ON, OFF, OFF, OFF
State Saved Yes
Range
OFF|ON
Integ BW
Sets the Integration Bandwidth for the offsets. Each resolution bandwidth in the list
corresponds to an offset frequency in the list defined by [:SENSe]:ACP:OFFSet[n]
[:OUTer]:LIST[:FREQuency].
Enter each value individually by selecting the desired offset, then enter the Offset
Integration Bandwidth.
You can turn off (not use) specific offsets with [:SENSe]:ACP:OFFSet[n]
[:OUTer]:LIST:STATe.
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth[:INTegration] <freq>,…
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth[:INTegration]?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:LIST:BAND 2MHz,2MHz,2MHz,2MHz,2MHz,2MHz
:ACP:OFFS2:LIST:BAND?
Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are
accepted without error but ignored
When setting these values remotely, the position in the list sent corresponds to the offset. Missing
values are not permitted, so, if you want to change the second value, you must send all values up to
that. Subsequent values remain unchanged, unless the number of values sent is greater than the
number of carriers, then subsequent values is ignored
Couplings Changing Integ BW might affect "Span" on page 955
Spectrum Analyzer Mode User's &Programmer's Reference 983
