Keysight x-series User Manual

6 Input/Output
6.9 Calibration
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:FATTenuation:STOP <rel_ampl>
:SYSTem:CALibration:ROW[1]|2|…|100:FATTenuation:STOP?
Example
:SYST:CAL:ROW3:FAT:PT:STOP 10
Dependencies Only appears in N9041B, when the RF input is selected, and the RF Input Port is set to RF Input 2, and
the Full Range Attenuator is installed
Disabled unless "Full Range Atten Type" on page 2503 is STEP
The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Couplings Coupled to Full Range Atten Start. Full Range Atten Stop must be >= Full Range Atten Start. If Full
Atten Stop < Full Range Atten Start, Full Range Atten Start = Full Range Atten Stop
Preset 20dB
State Saved Saved in instrument state
Min 0dB
Max Only valid values are 0, 6, 14, 20 dB
6.9.1.42 Frequency Extender Attenuation Type
Specifies the Frequency Extender Attenuation type to use. Frequency Extender
Attenuation is applied to the frequency extender’s high frequency input signal path
(for example, with a V3050A frequency extender, the high frequency path is 50GHz
to 110GHz).
–
STEP: Use multiple Frequency Extender Attenuation states determined by
Frequency Extender Attenuation Start and Frequency Extender Attenuation Stop
–
ALL: Use all the attenuator states
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:FEATtenuation:TYPE STEP | ALL
:SYSTem:CALibration:ROW[1]|2|…|100:FEATtenuation:TYPE?
Example
:SYST:CAL:ROW3:FEAT:TYPE STEP
Dependencies Only applies, and is only visible, when the External RF (ERFIN) input is selected
The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset
STEP
State Saved No
Range
STEP|ALL|REFerence
Spectrum Analyzer Mode User's &Programmer's Reference 2505
