3 Spectrum Analyzer Mode
3.8 Spurious Emissions Measurement
LTETDD, LTEATDD, 5G NR Modes: 150kHz, 30MHz, 1GHz, 1.90GHz, 2.01GHz, 2.025GHz, 12.75GHz,
2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz,
2.5GHz
LTE, LTEAFDD Modes: 150kHz, 30MHz, 1GHz, 1.92GHz, 1.98GHz, 2.1GHz, 12.75GHz, 2.5GHz, 2.5GHz,
2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz
WLAN Mode: 150kHz, 30 MHz, 1GHz, 12.75GHz, 2.5 GHz, 2.5 GHz, 2.5 GHz , 2.5 GHz, 2.5 GHz, 2.5
GHz, 2.5 GHz, 2.5 GHz, 2.5 GHz, 2.5 GHz, 2.5 GHz, 2.5 GHz, 2.5 GHz, 2.5 GHz, 2.5 GHz, 2.5 GHz
MSR Mode: 150kHz, 30MHz, 1GHz, 1.92GHz, 1.98GHz, 2.1GHz, 12.75GHz, 2.5GHz, 2.5GHz, 2.5GHz,
2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz
State Saved Yes
Min/Max -79999990/Hardware Dependent:
–
Option 503: 3.7 GHz
–
Option 508: 8.5 GHz
–
Option 513: 13.8 GHz
–
Option 526: 27.0 GHz
Center Frequency
Sets the frequency that corresponds to the horizontal center of the graticule. While
adjusting Center Frequency, display span is held constant (see "Range Settings" on
page 1436).
The Center Frequency setting is the same for all measurements within a Mode, that
is, it is Meas Global. Some Modes are also able to share a Mode Global center
frequency value. If this is the case, then a Global tab appears in the Meas Setup
menu.
The Center Frequency function sets (and queries) the center frequency for the
currently selected input. If your instrument has multiple inputs, and you select
another input, Center Frequency changes to the value for that input. SCPI
commands are available to directly set Center Frequency for a specific input.
Center Frequency is remembered as you go from input to input. Thus, you can set a
Center Frequency of 10GHz with the RF Input selected, change to BBIQ and set a
Center Frequency of 20MHz, then switch to External Mixing and set a Center
Frequency of 60GHz. When you return to the RF Input, Center Frequency reverts to
10GHz; back to BBIQ and it is 20MHz; back to External Mixing and it is 60GHz.
Remote Command
[:SENSe]:FREQuency:CENTer <freq>
[:SENSe]:FREQuency:CENTer?
Example Set Center Frequency to 50 MHz:
:FREQ:CENT 50 MHz
1440 Spectrum Analyzer Mode User's &Programmer's Reference
