3 Spectrum Analyzer Mode
3.6 Power Stat CCDF Measurement
:CALC:PST:MARK:COUP?
Preset
OFF
Presets on Mode Preset and All Markers Off
State Saved Saved in instrument state
3.6.7.3 Properties
The controls on this tab are used to set certain properties of the selected marker.
Marker X-Axis Value
This is the fundamental control that you use to move a marker around on the trace.
This is the same as "Marker X-Axis Value" on page 1201 in Settings.
Relative To
Selects the marker to which the selected marker is relative (its reference marker).
Every marker has another marker to which it is relative. This marker is referred to as
the “reference marker” for that marker. This attribute is set by the Marker,
Properties, Relative To key. The marker must be a Delta marker to make this
attribute relevant. If it is a Delta marker, the reference marker determines how the
marker is controlled and how its value is displayed. A marker cannot be relative to
itself.
Remote
Command
:CALCulate:PSTatistic:MARKer[1]|2|…|12:REFerence <integer>
:CALCulate:PSTatistic:MARKer[1]|2|…|12:REFerence?
Example
:CALC:PST:MARK:REF 3
:CALC:PST:MARK:REF?
Notes Causes the marker specified with the subopcode to become selected
Range (for SCPI command): 1 to 12. If the range is exceeded the value is clipped
A marker cannot be relative to itself so that choice is not available, and if sent from SCPI generates
error -221: “Settings conflict; marker cannot be relative to itself”
When queried, a single value is returned (the specified marker numbers relative marker)
Couplings The act of specifying the selected marker’s reference marker makes the selected marker a Delta marker
If the reference marker is off it is turned on in Fixed or Normal mode at the delta marker location
Preset The preset default “Relative To” marker (reference marker) is the next higher numbered marker (current
marker +1). For example, if marker 2 is selected, then it’s default reference marker is marker 3. The
exception is marker 12, which has a default reference of marker 1
Set to the defaults by using Restore Mode Defaults. This is not reset by Marker Off, All Markers Off, or
Preset
1204 Spectrum Analyzer Mode User's &Programmer's Reference
