3 Spectrum Analyzer Mode
3.6 Power Stat CCDF Measurement
Remote
Command
[:SENSe]:VOLTage|POWer:IQ:MIRRored OFF | ON | 0 | 1
[:SENSe]:VOLTage|POWer:IQ:MIRRored?
Example Turn off the mirroring of I Range to Q Range
:VOLT:IQ:MIRR OFF
:POW:IQ:MIRR OFF
Couplings When ON, the "I Range" on page 1972 value is mirrored (copied) to the "Q Range" on page 1973
Preset
ON
State Saved Saved in instrument state
Range
OFF|ON
3.6.3.4 Range (Non-attenuator models)
Only available for Keysight’s modular signal analyzers and certain other Keysight
products, such as VXT and M941xE.
State Saved No
Range
Represents the amplitude of the largest sinusoidal signal that could be present
within the IF without being clipped by the ADC. For signals with high peak-to-
average ratios, the range may need to exceed the rms signal power by a significant
amount to avoid clipping.
This is a measurement global setting.
Remote
Command
[:SENSe]:POWer[:RF]:RANGe <real>
[:SENSe]:POWer[:RF]:RANGe?
Example
:POW:RANG 10 dBm
:POW:RANG?
Notes The MIN and MAX values are affected by the External Gain parameters, and by the Center Frequency
The hardware compensates for frequency response and alters the Range setting
Preset 0 dBm
State Saved Yes
Min/Max –/+100
Annotation Meas Bar
1160 Spectrum Analyzer Mode User's &Programmer's Reference
