8 Trigger
8.6 Auto/Holdoff
8.6 Auto/Holdoff
Contains controls that let you adjust Auto Trigger and Trigger Holdoff parameters
This tab does not appear in Spectrum Analyzer Mode in VXT model M9421A.
8.6.1 Trig Holdoff
Sets the holdoff time between triggers. When the trigger condition is satisfied, the
trigger occurs, the delay begins, and the holdoff time begins. New trigger conditions
will be ignored until the holdoff time expires. For a free-running trigger, the holdoff
value is the minimum time between triggers.
Remote Command
:TRIGger[:SEQuence]:HOLDoff <time>
:TRIGger[:SEQuence]:HOLDoff?
Example
:TRIG:HOLD:STAT ON
:TRIG:HOLD 100 ms
Dependencies Unavailable if the selected Input is BBIQ. If this is the case, the control is grayed-out if it is pressed
the informational message “Feature not supported for this Input” is displayed. If the SCPI command is
sent, the error “Settings conflict; Feature not supported for this Input” is generated
Preset All modes except GSM/EDGE, LTEAFDD/TDD and 5G NR: 100 ms
GSM/EDGE, Bluetooth: 10 µs
LTEATDD: 19 ms
5G NR: 4 ms
State Saved Saved in instrument state
Min 0 s
Max 0.5 s
VXT models M9410A/11A/15A/16A: 2.86 s
Auto Function
Remote Command
:TRIGger[:SEQuence]:HOLDoff:STATe OFF | ON | 0 | 1
:TRIGger[:SEQuence]:HOLDoff:STATe?
Preset All modes but GSM/EDGE: OFF
GSM/EDGE mode: ON
8.6.2 Auto Trig
Sets the time that the instrument will wait for the trigger conditions to be met. If
they are not met after that much time, then the instrument is triggered anyway.
2701 Spectrum Analyzer Mode User's &Programmer's Reference
