Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.5 ACP Measurement
Modes Value
LTE, LTETDD 4.515 MHz|4.5 MHz
Radio Test 25 kHz
State Saved Saved in instrument state
Min/Max 10 Hz/Depends on instrument maximum frequency. Same as Max Span of the Swept SA Measurement
Backwards
Compatibility
SCPI
[:SENSe]:ACPower:BANDwidth:INTegration
[:SENSe]:ACPower:BWIDth:INTegration
[:SENSe]:ACPower:CARRier[1]|2:LIST:BWIDth[:INTegration]
[:SENSe]:MCPower:CARRier[1]|2:LIST:BANDwidth[:INTegration]
[:SENSe]:MCPower:CARRier[1]|2:LIST:BWIDth[:INTegration]
Method for Carrier
Accesses the carrier configuration method settings.
Remote
Command
[:SENSe]:ACPower:CARRier[1]|2:LIST:FILTer[:RRC][:STATe] ON | OFF | 1 | 0, …
[:SENSe]:ACPower:CARRier[1]|2:LIST:FILTer[:RRC][:STATe]?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:CARR:LIST:FILT 0,0,0,0
:ACP:CARR:LIST:FILT?
Notes The binary values translate as follows:
1|ON
RRC Weighted
0|OFF
Integ BW
Maximum of Array length depends on the number of carriers
Some Modes do not support Carrier subopcode 2. In those cases, commands with subopcode 2 are
accepted without error but ignored
For LTEAFDD or LTEATDD Modes, this control is not shown. In order to maintain backwards compat-
ibility with legacy LTE FDD/TDD Modes, the SCPI command is supported in the LTE & LTE-A converged
applications
Preset
Modes Value
SA, LTE, LTETDD
OFF
WCDMA
ON
Radio Test
OFF
State Saved Saved in instrument state
Range Integration BW | RRC Weighted
976 Spectrum Analyzer Mode User's &Programmer's Reference
