3 Spectrum Analyzer Mode

3.3 Channel Power Measurement

–

Resolution Bandwidth

–

Fundamental Frequency

–

Dwell Time

–

Range Table Resolution Bandwidths

–

Range Table Dwell Times

Meas Preset

Restores all measurement parameters to their default values.

Remote Command

:CONFigure:CHPower

Example

:CONF:CHP

3.3.8.2 Meas Method

Allows you to choose between Integration Bandwidth and RRC Weighted methods

of making the measurement, and to set certain other relevant parameters.

In MSR, LTE-A FDD/TDD and 5G NR Modes, this feature is not supported.

Meas Method

Selects either the Integration BW (OFF) or RRC Weighted (ON) methods. Selecting

the RRC Weighted method turns the Root Raised Cosine (RRC) filter on. The a value

(roll off) for the filter is set to the value of "RRC Filter Alpha" on page 647, and the

RRC filter bandwidth is set to "RRC Filter BW" on page 647.

Remote Command

[:SENSe]:CHPower:FILTer[:RRC][:STATe] OFF | ON | 0 | 1

[:SENSe]:CHPower:FILTer[:RRC][:STATe]?

Example

:CHP:FILT OFF

:CHP:FILT?

Notes This parameter is normally used when TETRA is selected as the Radio Std

Dependencies For WLAN 802.11 ac (80 + 80 MHz ), RRC Weighted is not supported

Preset

OFF

State Saved Saved in instrument state

Range Integration BW | RRC Weighted

646 Spectrum Analyzer Mode User's &Programmer's Reference
