3 Spectrum Analyzer Mode

3.8 Spurious Emissions Measurement

Adjust Atten for Min Clipping

Sets the combination of mechanical and electronic attenuation and gain based on

the current measured signal level so that clipping will be at a minimum.

This is an immediate action function, that is, it executes once, when the control is

pressed.

The algorithms that are used for the adjustment are documented under "Pre-Adjust

for Min Clipping" on page 1964.

Remote Command

[:SENSe]:POWer[:RF]:RANGe:OPTimize IMMediate

Example

:POW:RANG:OPT IMM

Notes Executing Adjust Atten for Min Clipping initiates the measurement

Dependencies Does not appear in the Swept SA, RTSA, Monitor Spectrum and Complex Spectrum measurements

Appears in the Waveform measurement in BASIC and 5G NR Modes

Adjust Atten

Allows you to select;

–

Electric attenuator only

–

Combination of Electric attenuator and Mechanical attenuator

when [:SENSe]:POWer[:RF]:RANGe:OPTimize IMMediate is executed.

Remote Command

[:SENSe]:POWer[:RF]:RANGe:OPTimize:TYPE EONLy | COMBined

[:SENSe]:POWer[:RF]:RANGe:OPTimize:TYPE?

Example

:POW:RANG:OPT:TYPE EONL

:POW:RANG:OPT:TYPE?

Dependencies Does not appear in the Swept SA, RTSA, Monitor Spectrum and Complex Spectrum measurements

Appears in the Waveform measurement in BASIC and 5G NR Modes

Preset

COMBined

State Saved Saved in instrument state

Pre-Adjust for Min Clipping

If this function is ON, it applies the adjustment described under "Adjust Atten for Min

Clipping" on page 1963 each time a measurement restarts. Therefore, in Continuous

measurement mode, it only executes before the first measurement.

Spectrum Analyzer Mode User's &Programmer's Reference 1377
