3 Spectrum Analyzer Mode
3.11 Harmonics Measurement
Remote
Command
[:SENSe]:HARMonics:SWEeptime:AUTO OFF | ON | 0 | 1
[:SENSe]:HARMonics:SWEeptime:AUTO?
[:SENSe]:HARMonics:SWEeptime:STATe OFF | ON | 0 | 1
[:SENSe]:HARMonics:SWEeptime:STATe?
Preset
ON
Sweep/Measure
Lets you toggle between Continuous and Single sweep or measurement operation.
The single/continuous state is Meas Global, so the setting affects all measurements.
The front-panel key Single/Cont performs exactly the same function
See "More Information" on page 1921
Remote
Command
:INITiate:CONTinuous OFF | ON | 0 | 1
:INITiate:CONTinuous?
Example Put instrument into Single measurement operation:
:INIT:CONT 0
:INIT:CONT OFF
Put instrument into Continuous measurement operation:
:INIT:CONT 1
:INIT:CONT ON
Preset
ON
Note that :SYST:PRES sets :INIT:CONT to ON, but *RST sets :INIT:CONT to OFF
State Saved Saved in instrument state
Annunciation The Single/Continuous icon in the Meas Bar changes depending on the setting:
–
A line with an arrow is Single
–
A loop with an arrow is Continuous
Backwards
Compatibility
Notes
X-Series A-models had Single and Cont hardkeys in place of the SweepSingleCont softkey. In the X-
Series A-models, if in single measurement, the Cont hardkey (and INIT:CONT ON) switched to
continuous measurement, but never restarted a measurement and never reset a sweep
X-Series B-models have a Cont/Single toggle control instead of Single and Cont hardkeys, but it is still
true that, if in single measurement, the Cont/Single toggle control never restarts a measurement and
never resets a sweep
More Information
Continuous
Mode
The instrument takes repetitive sweeps, averages, measurements, etc., when in
continuous mode. If in average or Max/Min Hold, and the average/hold count
reaches the Average/Hold Num, the count stops incrementing, but the instrument
Spectrum Analyzer Mode User's &Programmer's Reference 1921
