3 Spectrum Analyzer Mode
3.11 Harmonics Measurement
Preset
OFF
Range
OFF|ON
Range Table
Accesses a dialog that allows editing of the Range Table to control the
measurement parameters for each individual measurement.
Measure Tone
Sets whether the selected harmonic is measured (checked) or not measured
(unchecked). Harmonics that are not measured do not affect Total Harmonic
Distortion (THD).
When sending the Backwards Compatibility SCPI command below, send a complete
list of 10 states. Each harmonic will be made active or inactive depending on the
position. Thus, :HARM:RANG:STAT 1,0,1,0,1,0,0,0,0,0 turns on the third and
fifth harmonics. The Backwards Compatibility query returns 10 states.
Remote Command
[:SENSe]:HARMonics:TONE[1]|2|…|10:STATe OFF | ON | 0 | 1
[:SENSe]:HARMonics:TONE[1]|2|…|10:STATe OFF | ON | 0 | 1
Example Turn on the second tone (by default the second harmonic):
:HARM:TONE2:STAT ON
Preset
ON
Range
OFF|ON
Backwards Compatibility Command
Example
:HARM:RANG:STAT 1,0,1,0,1,0,0,0,0,0
Preset
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON
Backwards
Compatibility
SCPI
[:SENSe]:HARMonics:RANGe[:LIST]:STATe OFF | ON | 0 | 1, …
[:SENSe]:HARMonics:RANGe[:LIST]:STATe
Frequency
Sets the frequency of the selected harmonic. This overrides the normal frequency
calculation and allows non-integral harmonics to be measured.
When sending the Backwards Compatibility SCPI command below, send a complete
list of 10 frequencies. Each harmonic will have its frequency set appropriately. The
Backwards Compatibility query returns 10 frequencies.
1912 Spectrum Analyzer Mode User's &Programmer's Reference
