3 Spectrum Analyzer Mode

3.9 SEM Measurement

Preset 1 unless noted below:

2 WLAN

State Saved Saved in instrument state

Min/Max

MSR, LTEAFDD, LTEATDD, 5G NR Modes 1/4

All other Modes 1/3

3.9.11.1 Abs Pwr Freq

Displays the absolute power levels in dBm and the corresponding frequencies in the

text window.

Windows: "Graph" on page 1539, "Table" on page 1544

Example

:DISP:SEM:VIEW APFR

3.9.11.2 Rel Pwr Freq

Displays the relative power levels in dBc and the corresponding frequencies in the

text window.

Windows: "Graph" on page 1539, "Table" on page 1544

Example

:DISP:SEM:VIEW RPFR

3.9.11.3 Integrated Power

Displays the absolute and relative power levels integrated throughout the

bandwidths between the start and stop frequencies in the text window.

Windows: "Graph" on page 1539, "Table" on page 1544

Example

:DISP:SEM:VIEW IPOW

3.9.12 Windows

There are four available window types:

–

In all Modes, the "Graph" on page 1539 and "Table" on page 1544 windows are

available

–

When Gate View is on, the "Gate" on page 1554 window is available

This section describes the windows.

1538 Spectrum Analyzer Mode User's &Programmer's Reference
