10 Hardware-Accelerated Fast Power Measurement (Remote Command Only)

10.2 Reset Fast Power Measurement (Remote Command Only)

10.2.22 Trigger Timeout

Example

:CALC:FPOW:POW1:DEF "TriggerTimeout=0.1"

Notes Sets the time in which the instrument will wait for a trigger before automatically performing the

measurement

Preset 1 s

Range 0 – 1 s

10.2.23 Signal Input

Example

:CALC:FPOW:POW1:DEF "SignalInput=Fp50MHzCW"

Notes Lets you select between using the main RF input or the internal instrument reference CW signal of 50

MHz

Preset

FpMainRf

Range

FpMainRf, Fp50MHzCW

10.2.24 Use Preselector

Example

:CALC:FPOW:POW1:DEF "UsePreSelector=True"

Notes Lets you either utilize or bypass the front-end tunable filter at frequencies above 3.6 GHz. For

frequencies below 3.6 GHz, the preselector is automatically bypassed, so you do not need to set this

parameter to False in those cases

Preset

False

Range

True

Use preselector above 3.6 GHz

False

Preselector bypassed

10.2.25 Channel Bandwidth Array

Example

:CALC:FPOW:POW1:DEF "Bandwidth=[3.84e6, 5e6, 3.84e6]"

Notes Defines the bandwidth of each channel that will be measured

All array parameters should have the same number of elements. Alternatively, if all the elements are the

same value, a single number with no square brackets can be used to define the parameter

Preset [1e6]

Range 0 to 40 MHz

Spectrum Analyzer Mode User's &Programmer's Reference 2841
