Keysight x-series User Manual

6 Input/Output
6.9 Calibration
6.9.1.43 Frequency Extender Attenuation Start
Determines the first Frequency Extender Attenuator to be used in the Calibration.
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:FEATtenuation:STARt <rel_ampl>
:SYSTem:CALibration:ROW[1]|2|…|100:FEATtenuation:STARt?
Example
:SYST:CAL:ROW3:FEAT:STARt 0
Dependencies Only applies, and is only visible, when the External RF (ERFIN) input is selected
Disabled unless "Frequency Extender Attenuation Type" on page 2505 is STEP
The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Couplings Coupled to Frequency Extender Attenuation Stop. Frequency Extender Attenuation Start must be <=
Frequency Extender Attenuation Stop. If Frequency Extender Attenuation Start > Frequency Extender
Attenuation Stop, Frequency Extender Attenuation Stop = Frequency Extender Attenuation Start
Preset 0dB
State Saved Saved in instrument state
Min 0dB
Max V3050A: 26 dB
6.9.1.44 Frequency Extender Attenuation Stop
Determines the last Frequency Extender Attenuation to be used in the Calibration.
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:FEATtenuation:STOP <rel_ampl>
:SYSTem:CALibration:ROW[1]|2|…|100:FEATtenuation:STOP?
Example
:SYST:CAL:ROW3:FEAT:PT:STOP 26
Dependencies Only applies, and is only visible, when the External RF (ERFIN) input is selected
Disabled unless "Frequency Extender Attenuation Type" on page 2505 is STEP
The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Couplings Coupled to Frequency Extender Attenuation Start. Frequency Extender Attenuation Stop must be >=
Frequency Extender Attenuation Start. If Frequency Extender Attenuation Stop < Frequency Extender
Attenuation Start, Frequency Extender Attenuation Start = Frequency Extender Attenuation Stop
Preset 26dB
State Saved Saved in instrument state
Min 0dB
Max V3050A: 26 dB
2506 Spectrum Analyzer Mode User's &Programmer's Reference
