Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.6 Power Stat CCDF Measurement
Sets the Ref Level Offset to 12.7 dB. The only valid suffix is dB. If no suffix is sent, dB will be assumed
Dependencies Appears only in Spectrum Analyzer Mode
Preset 0 dBm
State Saved Saved in instrument state
Min The range for Ref Lvl Offset is variable. It is limited to values that keep the reference level within the
range of -327.6 dB to 327.6 dB
Max 327.6 dB
Annotation The offset is displayed as “Ref Offset <value>” to the right of the reference level annotation if nonzero.
When the offset is zero, no annotation is shown
Auto Function
Remote
Command
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEVel:OFFSet:STATe OFF | ON | 0 | 1
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEVel:OFFSet:STATe?
Example Turn Ref Level Offset ON:
:DISP:WIND:TRAC:Y:RLEV:OFFS:STAT ON
Preset
OFF
Minimum Probability
Sets the minimum probability range.
Remote
Command
:CALCulate:PSTatistic:RANGe[:PROBability]:MINimum PP2 | … | PP7
For parameter values, see "Parameter Options" on page 1138 below
:CALCulate:PSTatistic:RANGe[:PROBability]:MINimum?
Example
:CALC:PST:RANG:MIN PP6
:CALC:PST:RANG:MIN?
Preset
PP6
State Saved Yes
Range 1 % | 0.1 % | 0.01 % | 0.001 %| 0.0001 % | 0.00001 %
Parameter Options
Option Value
PP2
1.0e-2 (1 %)
PP3
1.0e-3 (0.1 %)
PP4
1.0e-4 (0.01 %)
PP5
1.0e-5 (0.001 %)
1138 Spectrum Analyzer Mode User's &Programmer's Reference
