Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.8 Spurious Emissions Measurement
LTETDD, LTEATDD, 5G NR: 9 kHz, 150 kHz, 30 MHz, 1 GHz, 1.90GHz, 2.01 GHz, 2.025 GHz, 1.5 GHz,
1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5
GHz
LTE, LTEAFDD: 9 kHz, 150 kHz, 30 MHz, 1 GHz, 1.92GHz, 1.98 GHz, 2.18 GHz, 1.5 GHz, 1.5 GHz, 1.5
GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz
WLAN:
9 kHz, 150 kHz, 30 MHz, 1GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5
GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz
MSR: 9 kHz, 150 kHz, 30 MHz, 1 GHz, 1.92GHz, 1.98 GHz, 2.18 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5
GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz, 1.5 GHz
State Saved Saved in instrument state
Min/Max -80 MHz/Hardware Dependent:
–
Option 503: 3699999990
–
Option 508: 8499999990
–
Option 513: 13799999990
–
Option 526: 26999999990
Stop Freq
Sets the stop frequency of the instrument. This parameter can send up to 20 values.
When sending the remote command, missing values are not permitted. If you want
to change values 2 and 6, then you must send all values up to 6. Subsequent values
will remain as they were.
The query always returns 20 values.
Remote
Command
[:SENSe]:SPURious[:RANGe][:LIST]:FREQuency:STOP <freq>, <freq>, <freq>,
<freq>, <freq>, <freq>, <freq>, <freq>, <freq>, <freq>, <freq>, <freq>,
<freq>, <freq>, <freq>, <freq>, <freq>, <freq>, <freq>, <freq>
[:SENSe]:SPURious[:RANGe][:LIST]:FREQuency:STOP?
Example
:SPUR:FREQ:STOP 150kHz, 30MHz, 1GHz, 2.1GHz, 2.1GHz, 2.1774GHz, 2.18GHz,
12.75GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz,
2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz
:SPUR:FREQ:STOP?
Preset SA Mode: +1.98000000E+009, +1.91960000E+009, +2.10150000E+009, +2.18000000E+009,
+1.00000000E+009, +2.50000000E+009, +2.50000000E+009, +2.50000000E+009,
+2.50000000E+009, +2.50000000E+009, +2.50000000E+009, +2.50000000E+009,
+2.50000000E+009, +2.50000000E+009, +2.50000000E+009, +2.50000000E+009,
+2.50000000E+009, +2.50000000E+009, +2.50000000E+009, +2.50000000E+009
WCDMA Mode: 150kHz, 30MHz, 1GHz, 2.1GHz, 2.1GHz, 2.1774GHz, 2.18GHz, 12.75GHz, 2.5GHz,
2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz, 2.5GHz
Spectrum Analyzer Mode User's &Programmer's Reference 1439
