3 Spectrum Analyzer Mode
3.5 ACP Measurement
Conditions Results
# Item Unit, if any
11 Upper offset B - relative power dB
12 Upper offset B - absolute power dBm/Hz or dBm/MHz*
... ... ...
When "Max Num of Offsets" on page 1010 is 6, returns 28 results (Offset A-F: 28 = 4 + 4*6) and
when set to 12, returns 52 results (Offset A-L: 52 = 4 + 4 * 12)
*The unit is determined by "PSD Unit" on page 1063: DBMHZ or DBMMHZ
If any result is not available, -999.0 is returned
For SA Mode, the values are in the current Y Axis Unit of the instrument
3.5.2 Measurement Results for n = 2
–
For SA Mode, the values are in the current Y Axis Unit of the instrument
–
For MSR, LTE Advanced FDD/TDD, and 5G NR Modes, this trace includes only
outer offset results and their reference value(s)
Measurement Type = Total power reference
For the trace specified by "Measure Trace" on page 1754, returns comma-separated
scalar results in the following order:
# Item Result Unit, if any
1 Channel (1) Relative power dB
2 Channel (1) Absolute power dBm
3 Channel (2) Relative power dB
4 Channel (2) Absolute power dBm
... ... …
23 Channel (12) Relative power dB
24 Channel (12) Absolute power dBm
25 Lower offset A Relative power dB
26 Lower offset A Absolute power dBm
27 Upper offset A Relative power dB
28 Upper offset A Absolute power dBm
29 Lower offset B Relative power dB
30 Lower offset B Absolute power dBm
31 Upper offset B Relative power dB
Spectrum Analyzer Mode User's &Programmer's Reference 877
