3 Spectrum Analyzer Mode
3.12 List Sweep Measurement (Remote Only)
State Saved Saved in instrument state
Range Fast Tuning (3)
Best Phase Noise for offsets <20kHz (2)
Best Phase Noise for offsets >30kHz (1)
Min 1
Max 3
3.12.3.10 Detector List
This command defines a list of analyzer detector settings at which the
measurements are made. The choice of detectors is different from the choice in
other measurements.
The query form queries the analyzer for the values in the detector list.
Remote
Command
[:SENSe]:LIST:DETector <type>[, <type>]
[:SENSe]:LIST:DETector?
Example
LIST:DET POS
Remote
Command Notes
LAVG : average detector. Average detected on the log scale.
VAVG : average detector. Average detected on the voltage scale.
RMS: average detector. Average detected on the power (rms) scale.
NEGative: negative peak detector.
POSitive: positive peak detector.
SAMPle: sample detector.
PKAV: Peak-AVER detector, a newly defined term, would allow the simultaneous measurement and
two-point reporting of the results of the positive peak and the average detector (voltage scale).
PRMS: Peak-RMS detector, a newly defined term, would allow the simultaneous measurement and
two-point reporting of the results of the positive peak and the average detector (rms scale).
DAVG: DualAvg detector is similarly a newly defined term that allows two-point reporting of simultan-
eously made measurements. With this detector, one result (the former) is average detected on the
power (rms) scale, and one is average detected on the voltage scale.
Preset LAVG
State Saved Saved in instrument state
Range LAVG | VAVG | RMS | NEGative | POSitive | SAMPle | PKAV | PRMS | DAVG
Remote Command
[:SENSe]:LIST:DETector:POINts?
Example
LIST:DET:POIN?
Spectrum Analyzer Mode User's &Programmer's Reference 1941
