Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.5 ACP Measurement
Integ BW
Sets the Integration Bandwidth for the offsets. Each resolution bandwidth in the list
corresponds to an offset frequency in the list defined by [:SENSe]:ACP:OFFSet
[n]:INNer:LIST[:FREQuency].
Enter each value individually by selecting the desired offset on the Offset menu key
using the up down arrows, the knob, or the numeric keypad, then enter the Offset
Integration Bandwidth using the Offset Integration Bandwidth menu key.
You can turn off (not use) specific offsets with [:SENSe]:ACP:OFFSet
[n]:INNer:LIST:STATe.
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth[:INTegration] <freq>,…
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth[:INTegration]?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:INN:LIST:BAND 2MHz,2MHz,2MHz,2MHz,2MHz,2MHz
:ACP:OFFS2:INN:LIST:BAND?
Notes When setting these values remotely, the position in the list sent corresponds to the offset. Missing
values are not permitted, so, if you want to change the second value you must send all values up to it.
Subsequent values remain unchanged
Couplings Changing Integ BW might affect "Span" on page 955
Preset When "Max Num of Offsets" on page 1010 is 12, the preset value of Offset G ~ L is the same as the
Offset F value
Modes Values
LTEAFDD 3.84MHz, 3.84MHz, 3.84MHz, 3.84MHz, 3.84MHz, 3.84MHz | 3.84MHz,
3.84MHz, 3.84MHz, 3.84MHz, 3.84MHz, 3.84MHz
MSR,
LTEATDD
4.515MHz, 4.515MHz, 4.515MHz, 4.515MHz, 4.515MHz, 4.515MHz | 4.5MHz,
4.5MHz, 4.5MHz, 4.5MHz, 4.5MHz, 4.5MHz
5G NR 19.08 MHz, 19.08 MHz, 19.08 MHz, 19.08 MHz, 19.08 MHz, 19.08 MHz | 98.31
MHz, 98.31 MHz, 98.31 MHz, 98.31 MHz, 98.31 MHz, 98.31 MHz
State Saved Saved in instrument state
Min/Max 10 Hz/Depends on instrument maximum frequency. Same as Max Span of the Swept SA Measurement
Offset Side
Lets you turn off (not use) specific offsets with [:SENSe]:ACPower:OFFSet
[1]|2:INNer:LIST:SIDE.
–
NEGative - The upper side in the sub-block gap only (that is, negative sideband
of the upper sub-block) is enabled
1042 Spectrum Analyzer Mode User's &Programmer's Reference
