3 Spectrum Analyzer Mode
3.5 ACP Measurement
Preset When "Max Num of Offsets" on page 1010 is 12, the preset value of Offset G ~ L is the same as the
Offset F value
Modes Values
LTEAFDD 1,1,1,1,1,1 | 1,1,1,1,1,1
MSR, LTEATDD, 5G NR 0,0,0,0,0,0 | 0,0,0,0,0,0
State Saved Saved in instrument state
Range Integ BW | RRC Weighted
Filter Alpha
Sets the alpha value for the RRC Filter for each offset.
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:FILTer:ALPHa <real>,…
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:FILTer:ALPHa?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:INN:LIST:FILT:ALPH 0.5,0.5,0.5,0.5,0.5,0.5
:ACP:OFFS:INN:LIST:FILT:ALPH?
Preset When "Max Num of Offsets" on page 1010 is 12, the preset value of Offset G ~ L is 0.22
0.22,0.22,0.22,0.22,0.22,0.22|0.22,0.22,0.22,0.22,0.22,0.22
State Saved Saved in instrument state
Min/Max 0.01/1.00
Offset Freq
The same as "Offset Freq" on page 1040 in the main Inner Offset menu.
Res BW
Sets the Resolution Bandwidth. If an unavailable bandwidth is entered with the
numeric keypad, the closest available bandwidth is selected.
Remote Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:RESolution <freq>,…
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:RESolution?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:INN:LIST:BAND:RES 220kHz,220kHz,220kHz,220kHz,220kHz,220kHz
:ACP:OFFS2:INN:LIST:BAND:RES?
Dependencies When "Meas Method" on page 970 is RBW, FAST or Fast Power, this control is grayed-out and
disabled. If the cell is pressed, an advisory message is generated. If the equivalent SCPI remote
1044 Spectrum Analyzer Mode User's &Programmer's Reference
