3 Spectrum Analyzer Mode
3.11 Harmonics Measurement
parameter
value;
View
<alphanumeric>
does
not
exist”
is
generated
If the current View is a Predefined View, the error message “-224, Illegal parameter value; Cannot
delete a Predefined View” is generated
If the display is disabled (via :DISP:ENAB OFF) then the error message “-221, Settings conflict;
View SCPI cannot be used while Display is disabled” is generated
Delete All User Views
Deletes all previously saved User Views. The default view becomes the current view
for the Measurement if a User View was the current view when this command was
executed.
Remote
Command
:DISPlay:VIEW:ADVanced:DELete:ALL
Example
:DISP:VIEW:ADV:DEL:ALL
Notes Disabled if there are no User Views
View Editor Remote Commands
The following remote commands help you manage Views and User Views. Note that
the SCPI node for User Views handles both Predefined and User Views. The legacy
nodes, :DISPlay:VIEW[:SELect] and :DISPlay:VIEW:NSEL, are retained for
backwards compatibility, but they only support predefined views.
View Listing Query
Returns a string containing a comma-separated list of names for all the Views,
including User Views, available for the current Measurement.
Remote
Command
:DISPlay:VIEW:ADVanced:CATalog?
Example
:DISP:VIEW:ADV:CAT?
Notes Returns a quoted string of the available Views for the current measurement, separated by commas. The
list includes names for all the Views, including User Views, available for the current Measurement
Example:
"Normal,Trace Zoom,Spectrogram,Baseband,myView1,yourView1"
No distinction is made between Predefined and User Views
If you switch measurements with the display disabled (via :DISP:ENAB OFF), then query the list of
available Views, the result is undefined
1906 Spectrum Analyzer Mode User's &Programmer's Reference
