3 Spectrum Analyzer Mode
3.2 Swept SA Measurement
Preset
ON
Set by :SYST:DEF MISC, but not affected by *RST or :SYSTem:PRESet
State Saved Not saved in instrument state
Backwards
Compatibility
Notes
:SYST:PRES no longer turns on :DISPlay:ENABle as it did in legacy analyzers
3.2.5.3 View
Contains controls for selecting the current View, and for editing User Views.
View
See "Views" on page 187
User View
Lets you choose a View from the saved User Views for the current measurement.
This panel only appears if a User View exists for the current measurement.
Remote
Command
:DISPlay:VIEW:ADVanced:SELect
<alphanumeric>
:DISPlay:VIEW:ADVanced:SELect?
Example Select Baseband as the current View
:DISP:VIEW:ADV:SEL “Baseband”
Notes You must be in the measurement whose View you are trying to set to send the command. You can only
set Views for the current measurement using this command
For predefined views, the parameter is derived from the view name that is shown in the View list in the
user interface. For example, if you are trying to select the Trace Zoom view in the Swept SA
measurement, you send:
:DISP:VIEW:ADV:SEL "Trace Zoom"
because “Trace Zoom” is the name of the View as seen in the Mode/Meas dialog or in the Display, View
menu
You cannot use the legacy View parameter (which in this case would be TZOom) with
:DISP:VIEW:ADV:SEL
<alphanumeric> is case insensitive; you can specify mixed case, however the name will be
evaluated on a single case. Thus, both of the following forms work:
:DISP:VIEW:ADV:SEL "Trace Zoom"
:DISP:VIEW:ADV:SEL "TRACE ZOOM"
If the specified view is not a valid View, the query returns the error message “-224, Illegal parameter
value;
View
with
the
name
<alphanumeric>
does
not
exist”
If the display is disabled (via :DISP:ENAB OFF) then the error message “-221, Settings conflict;
Spectrum Analyzer Mode User's &Programmer's Reference 277
