Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.5 ACP Measurement
RBW Filter BW
Selects a Gaussian filter based on its –3 dB (Normal) bandwidth or its –6 dB
bandwidth.
Remote Command
[:SENSe]:ACPower:BANDwidth:TYPE DB3 | DB6
[:SENSe]:ACPower:BANDwidth:TYPE?
Example
:ACP:BAND:TYPE DB3
:ACP:BAND:TYPE?
Dependencies Disabled when "RBW Filter Type" on page 940 is FLATtop or "Meas Method" on page 970 is RBW,
FAST, or Fast Power
If pressed, an advisory message is generated. If the equivalent command is sent, a "Setting conflict"
warning is generated
Preset
DB3
State Saved Saved in instrument state
Range –3 dB (Normal)|–6 dB
Backwards
Compatibility SCPI
[:SENSe]:ACPower:BWIDth:TYPE
3.5.10 Display
Lets you configure display items for the current Mode, Measurement, View, or
Window.
3.5.10.1 Meas Display
Contains controls for setting up the display for the current Measurement, View or
Window.
Bar Graph On/Off
Turns the Bar Graph On or Off.
Remote Command
:DISPlay:ACPower:WINDow[1]:BGRaph OFF | ON | 0 | 1
:DISPlay:ACPower:WINDow[1]:BGRaph?
Example
:DISP:ACP:WIND:BGR OFF
:DISP:ACP:WIND:BGR?
Dependencies Always set to ON and grayed-out when the method is RBW
Preset
ON
Spectrum Analyzer Mode User's &Programmer's Reference 941
