3 Spectrum Analyzer Mode
3.9 SEM Measurement
:SEM:OFFS2:LIST:BAND:VID:AUTO?
Notes Comma separated list of values
OFFSet1 is for BTS, 2 for MS. Default is BTS
Note that Offset sub op code 2 is supported only in non-SA modes. In the SA mode, Offset sub op code
1 is used for both BTS and MS
Preset Automatically Calculated
When the max number of offsets is 6:
ON, ON, ON, ON, ON, ON | ON, ON, ON, ON, ON, ON
When the max number of offsets is 12:
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON | ON, ON, ON, ON, ON, ON,
ON, ON, ON, ON, ON, ON
When the max number of offsets is 14:
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON
State Saved Saved in instrument state
Saved in instrument state
Range Auto|Man
Min/Max 1 Hz/50 MHz
Backwards
Compatibility
SCPI
[:SENSe]:SEMask:OFFSet[1]|2:LIST:BWIDth:VIDeo
[:SENSe]:SEMask:OFFSet[1]|2:LIST:BWIDth:VIDeo:AUTO
VBW/RBW
Selects the ratio between the video and resolution bandwidths.
When sending the remote command, missing values are not permitted; that is, if you
want to change values 2 and 6, you must send all values up to 6. Subsequent values
will remain unchanged. The query for this parameter returns 14 values for WLAN
mode, 12 values for other modes.
Remote
Command
[:SENSe]:SEMask:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:VIDeo:RATio <real>, …
[:SENSe]:SEMask:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:VIDeo:RATio?
[:SENSe]:SEMask:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:VIDeo:RATio:AUTO OFF | ON
| 0 | 1, …
[:SENSe]:SEMask:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:VIDeo:RATio:AUTO?
Example
:SEM:OFFS2:LIST:BAND:VID:RAT 0.1, 0.1, 0.1, 0.1, 0.1, 0.1
:SEM:OFFS2:LIST:BAND:VID:RAT?
:SEM:OFFS2:LIST:BAND:VID:RAT:AUTO ON, ON, ON, ON, ON, ON
:SEM:OFFS2:LIST:BAND:VID:RAT:AUTO?
Notes Comma separated list of values
Spectrum Analyzer Mode User's &Programmer's Reference 1641
