3 Spectrum Analyzer Mode
3.10 TOI Measurement
Remote Command
[:SENSe]:SWEep:IF:DITHer OFF | ON | 0 | 1
[:SENSe]:SWEep:IF:DITHer?
Dependencies Only appears in Spectrum Analyzer Mode in VXT models
Preset
OFF
State Saved Saved in instrument state
Image Protection
Lets you turn IF Protection on or off. This is a technique used in unpreselected
instruments (such as Keysight’s modular instruments) to detect and suppress
images and spurs that may be present in non-preselected hardware.
IF Protection takes two sweeps and by correlating the data between them, provides
a single, correct power-versus-frequency trace.
Remote Command
[:SENSe]:SWEep:IMAGeprot OFF | ON | 0 | 1
[:SENSe]:SWEep:IMAGeprot?
Dependencies Only appears in Spectrum Analyzer Mode in VXT models
Preset
ON
State Saved Saved in instrument state
3.10.10 Trace
The controls in this menu let you control the acquisition, display, storage, detection
and manipulation of trace data for the available traces. The "Trace Control" on page
1926 tab contains radio-button selections for the trace type (Clear/Write, Trace
Average, Max Hold, Min Hold) and View/Blank setting for the selected trace.
3.10.10.1 Trace Control
The controls on this tab allow you to set the "Trace Type" on page 1927 and its
update mode.
There are four Trace Types:
–
Clear/Write
–
Trace Average
–
Max Hold
–
Min Hold
Each type handles data in a different way.
Spectrum Analyzer Mode User's &Programmer's Reference 1845
