Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.5 ACP Measurement
This function does not work when Band Lock under System > Service > Lock
Functions is not -1 (no Band Lock). In that case, Band Lock takes priority over
Extend Low Band.
This function resets to OFF when "Restore Defaults" on page 2037 is pressed, or
when System, Restore Defaults, All Modes is pressed.
Remote
Command
:INSTrument:COUPle:FREQuency:BAND:EXTend 0 | 1 | ON | OFF
:INSTrument:COUPle:FREQuency:BAND:EXTend?
Example
:INST:COUP:FREQ:BAND:EXT 1
:INST:COUP:FREQ:BAND:EXT?
Preset Set to OFF by Global Settings > Restore Defaults and System > Restore Defaults > All Modes
Range
ON|OFF
Restore Defaults
Resets all functions in the Global settings menu to OFF. Pressing System, Restore
Defaults, All Modes has the same effect.
Remote Command
:INSTrument:COUPle:DEFault
Example
:INST:COUP:DEF
Backwards Compatibility
SCPI
:GLOBal:DEFault
3.5.13.6 Offset RRC Weighting (Backwards Compatibility SCPI)
Example
:ACP:FILT OFF
:ACP:FILT?
Couplings This command is an alias of:
[:SENSe]:ACPower:OFFSet[1]|2:LIST:FILTer[:RRC][:STATe]
Sending the command sets values of all offsets for BS and MS, but the query always returns a value of
BS Offset A
Preset
SA, LTEAFDD, LTEATDD, MSR
OFF
WCDMA
ON
State Saved Yes
Backwards
Compatibility
SCPI
[:SENSe]:ACPower:FILTer[:RRC][:STATe] OFF | ON | 0 | 1
[:SENSe]:ACPower:FILTer[:RRC][:STATe]?
[:SENSe]:ACPR:FILTer[:RRC][:STATe]
[:SENSe]:MCPower:FILTer[:RRC][:STATe]
1094 Spectrum Analyzer Mode User's &Programmer's Reference
