Keysight x-series User Manual

6 Input/Output
6.9 Calibration
Example
:SYST:CAL:ROW3:IF:GAIN ALL
Dependencies The SCPI command applies to the current selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset
AUTO
State Saved Saved in instrument state
Range Auto | High Gain | Low Gain | All
6.9.1.48 Preamp
Determines if the Preamp is to be used in the Calibration
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:POWer[:RF]:GAIN:BAND OFF | LOW | FULL
:SYSTem:CALibration:ROW[1]|2|…|100:POWer:GAIN:BAND?
Example
:SYST:CAL:ROW2:POWer:GAIN:BAND OFF
Dependencies The SCPI command applies to the current selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset
OFF
State Saved Saved in instrument state
Range
OFF|LOW|FULL
6.9.1.49 Low Noise Amplifier (LNA)
Determines if the LNA is to be used in the Calibration.
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:POWer[:RF]:GAIN:LNA[:STATe] ON | OFF | 1
| 0
:SYSTem:CALibration:ROW[1]|2|…|100:POWer[:RF]:GAIN:LNA[:STATe]?
Example
:SYST:CAL:ROW2:POW:GAIN:LNA ON
:SYST:CAL:ROW2:POW:GAIN:LNA?
Dependencies The SCPI command is applied to the currently selected Cal Group. The subopcode is used to identify
the Cal row in the Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset
OFF
State Saved No
Range
ON|OFF
Spectrum Analyzer Mode User's &Programmer's Reference 2509
