Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.9 SEM Measurement
WLAN Mode Presets
Radio Std Presets
802.11b/g (DSSS/CCK/PBCC)
REL, REL, REL, REL, REL, REL, REL,
REL, REL, REL, REL, REL, REL, REL
802.11a/g (OFDM/DSSS-OFDM)
REL, REL, REL, AND, AND, AND, AND,
AND, AND, AND, AND, AND, AND, AND
802.11n/ac/ax/be (20 MHz/ 40 MHz/ 80
MHz/80 MHz + 80MHz / 160 MHz/320MHz)
AND, AND, AND, AND, AND, AND, AND,
AND, AND, AND, AND, AND, AND, AND
802.11ah (1MHz/ 2 MHz/ 4 MHz/ 8 MHz/ 16
MHz)
REL, REL, REL, AND, AND, AND, AND,
AND, AND, AND, AND, AND, AND, AND
802.11j/p 10M, p5M
REL, REL, REL, AND, AND, AND, AND,
AND, AND, AND, AND, AND, AND, AND
802.11af (6 MHz/ 7 MHz/ 8 MHz)
REL, REL, REL, AND, AND, AND, AND,
AND, AND, AND, AND, AND, AND, AND
Show Abs2 Limit
Shows or hides Abs2 limit parameters.
Remote
Command
:DISPlay:SEMask:OFFSet:SABSolute ON | OFF | 1 | 0
:DISPlay:SEMask:OFFSet:SABSolute?
Example
:DISP:SEM:OFFS:SABS 1
:DISP:SEM:OFFS:SABS?
Preset 0
State Saved Yes
Range
ON|OFF
Abs2 Start
Sets the 2nd absolute power level limit at the start frequency for the selected offset,
ranging from –200 to +50 dBm.
The fail condition for each offset channel is set remotely using:
[:SENSe]:SEMask:OFFSet[n][:OUTer]:LIST:TEST:SABSolute
You can turn off (not use) specific offset channels remotely using:
[:SENSe]:SEMask:OFFSet[n][:OUTer]:LIST:STATe
The query returns values currently set to the 2nd absolute power test limits.
When sending the command, missing values are not permitted; that is, if you want
to change values 2 and 6, you must send all values up to 6. Subsequent values
Spectrum Analyzer Mode User's &Programmer's Reference 1661
