3 Spectrum Analyzer Mode
3.9 SEM Measurement
From Trace
Selects the trace to be copied to or exchanged with the "To Trace" on page 1752
when a "Copy" on page 1752 or "Exchange" on page 1753 is performed
Preset 1
To Trace
Selects the trace to be copied from or exchanged with the "From Trace" on page
1752 when a "Copy" on page 1752 or "Exchange" on page 1753 is performed
Preset 2
Copy
Executes a Trace Copy based on the "From Trace" on page 1752 and "To Trace" on
page 1752 parameters. The copy operation is from the From Trace to the To Trace.
The action is performed once.
The X-Axis settings and domain of a trace are also copied.
Remote Command For Swept SA Measurement (in SA Mode):
:TRACe:COPY TRACE1 | … | TRACE6, TRACE1 | … | TRACE6
For all other measurements:
:TRACe:<meas>:COPY TRACe1 | TRACe2 | TRACe3, TRACe1 | TRACe2 | TRACe3
where <meas> is the identifier for the current measurement
Note that the format of the TRACe<n> parameter differs from that for the Swept SA Measurement
Example Copy Trace 1 to Trace 3 and put Trace 3 in Update=Off, Display=On
:TRAC:COPY TRACE1,TRACE3
Notes The command is of the form:
:TRACe:COPY <source_trace>,<dest_trace>
Dependencies When Signal ID is on, this key is grayed-out
Couplings The destination trace is put in View (Update = Off, Display = On) after the copy
Preset For Swept SA Measurement (in SA Mode):
TRACE1, TRACE2
For all other measurements:
TRACe1, TRACe2
1752 Spectrum Analyzer Mode User's &Programmer's Reference
