3 Spectrum Analyzer Mode
3.9 SEM Measurement
Res BW
Sets the resolution bandwidth used to calculate the power in the reference channel.
The Channel Resolution BW can be set manually or put into auto mode.
MSR Auto RBW:
In the MSR Mode, resolution bandwidth is predefined for each radio format. When
carriers are configured with multiple radio formats, the narrowest RBW is selected.
Radio Format RBW (kHz)
LTE 1.4 MHz 13 kHz
3 MHz 27 kHz
5 MHz 47 kHz
10 MHz 91 kHz
15 MHz 150 kHz
20 MHz 180 kHz
200 kHz (NB-IoT, only available in FDD) 10 kHz
W-CDMA 75 kHz
5G NR Auto RBW:
Radio Format RBW
5G NR 5 MHz 47 kHz
10 MHz 91 kHz
15 MHz 150 kHz
20 MHz 180 kHz
25 MHz 240 kHz
30 MHz 270 kHz
35 MHz 330 kHz
40 MHz 390 kHz
45 MHz 430 kHz
50 MHz 470 kHz
60 MHz 560 kHz
70 MHz 680 kHz
80 MHz 750 kHz
90 MHz 820 kHz
100 MHz 910 kHz
200MHz 1.8 MHz
400 MHz 3 MHz
Spectrum Analyzer Mode User's &Programmer's Reference 1695
