Keysight x-series User Manual

6 Input/Output
6.9 Calibration
Preset 1
Min 1
Max 100000
6.9.1.31 Mech Atten Type
Specifies the Mech Atten type to use:
–
STEP: Use multiple Mech Atten states determined by Mech Atten Start, Mech
Atten Stop and Mech Atten Step
–
ALL: Use all the attenuator states
–
BYPass: Bypasses the attenuator
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:ATTenuation:TYPE STEP | ALL | BYPass
:SYSTem:CALibration:ROW[1]|2|…|100:ATTenuation:TYPE?
Example
:SYST:CAL:ROW3:ATT:TYPE STEP
Dependencies The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-
221,Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset
STEP
State Saved Saved in instrument state
Range
STEP|ALL|BYPass
6.9.1.32 Mech Atten Start
Determines the first Mechanical Attenuator to be used in the Calibration
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:ATTenuation:STARt <rel_ampl>
:SYSTem:CALibration:ROW[1]|2|…|100:ATTenuation:STARt?
Example
:SYST:CAL:ROW3:ATT:STARt 20
Dependencies Disabled unless "Mech Atten Type" on page 2499 is STEP
The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-
221,Settings conflict; Subopcode does not reference an existing Cal row” is generated
Couplings Coupled to "Mech Atten Stop" on page 2500. Mech Atten Start must be <= Mech Atten Stop. If Mech
Atten Start > Mech Atten Stop, then Mech Atten Stop = Mech Atten Start
Preset 10dB
State Saved Saved in instrument state
Min 0dB
Spectrum Analyzer Mode User's &Programmer's Reference 2499
