6 Input/Output
6.9 Calibration
6.9.1.50 µW Path Control
Determines the µW Path Control to be used in the Calibration.
Option SCPI
Standard Path
STD
Low Noise Path
LNPath
µW Presel Bypass
MPBypass
Full Bypass
FULL
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:POWer[:RF]:MW:PATH STD | LNPath |
MPBypass | FULL
:SYSTem:CALibration:ROW[1]|2|…|100:POWer[:RF]:MW:PATH?
Example
:SYST:CAL:ROW2:POW:MW:PATH FULL
Dependencies The SCPI command applies to the current selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
This column is not shown in the table unless either Option MPB or Option LNB is present and licensed
The Low Noise Path selection does not appear unless Option LNP is present and licensed
The µW Presel Bypass selection does not appear unless Option MPB is present and licensed
The Full Bypass selection does not appear unless Options LNP, MPB and FBP are installed and
licensed
In any of these cases, if the required options are not present and the SCPI command is sent, error -
241, "Hardware missing; Option not installed" is generated
Preset
STD
State Saved Saved in instrument state
Range
STD|LNPath|MPBypass|FULL
6.9.1.51 Coupling
Determines the Coupling to be used in the Calibration
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:COUPling AC | DC
:SYSTem:CALibration:ROW[1]|2|…|100:COUPling?
Example
:SYST:CAL:ROW3:COUP AC
Dependencies The SCPI command applies to the current selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
Preset
AC
2510 Spectrum Analyzer Mode User's &Programmer's Reference
