3 Spectrum Analyzer Mode
3.7 Burst Power Measurement
Ref Position
Sets the reference position for the X axis to Left, Center or Right.
Remote
Command
:DISPlay:TXPower:WINDow[1]:TRACe:X[:SCALe]:RPOSition LEFT | CENTer | RIGHt
:DISPlay:TXPower:WINDow[1]:TRACe:X[:SCALe]:RPOSition?
Example
:DISP:TXP:WIND:TRAC:X:RPOS LEFT
:DISP:TXP:WIND:TRAC:X:RPOS?
Preset
LEFT
State Saved Saved in instrument state
Range
LEFT|CENTer|RIGHt
Backwards
Compatibility
SCPI
:DISPlay:TXPower:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RPOSition
Auto Scaling
Toggles the scale coupling function On or Off.
Remote
Command
:DISPlay:TXPower:WINDow[1]:TRACe:X[:SCALe]:COUPle 0 | 1 | OFF | ON
:DISPlay:TXPower:WINDow[1]:TRACe:X[:SCALe]:COUPle?
Example
:DISP:TXP:WIND:TRAC:X:COUP OFF
:DISP:TXP:WIND:TRAC:X:COUP?
Couplings When ON, and the Restart front-panel key is pressed, this function automatically determines the scale
per division and reference values based on the measurement results
When you set the value of either "Scale/Div" on page 1242 or "Ref Value" on page 1242 manually, Auto
Scaling automatically changes to OFF
Preset
ON
State Saved Saved in instrument state
Range
OFF|ON
Backwards
Compatibility
SCPI
:DISPlay:TXPower:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:COUPle
3.7.10 Trace
Lets you control the acquisition, display, storage, detection and manipulation of
trace data for the available traces.
1350 Spectrum Analyzer Mode User's &Programmer's Reference
