Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.9 SEM Measurement
# Item Unit, if any
19
10k + 19,
k = 0
Absolute peak power on the positive offset A When "Measurement Type" on page 1700
is PSD Ref: dBm/Hz
Others: dBm
20
10k + 20,
k = 0
Peak power offset frequency from the center or carrier edge
frequency in the positive offset A
Depends on the setting of "Offset Freq Define" on page 1642
Hz
---
70
10k + 20,
k = 5
Peak power offset frequency from the center or carrier edge
frequency in the positive offset F
Depends on the setting of "Offset Freq Define" on page 1642
Hz
71
2k + 71, k
= 0
Minimum margin from limit line on the negative offset A dB
72
2k + 72, k
= 0
Minimum margin from limit line on the positive offset A dB
---
82
2k + 72, k
= 5
Minimum margin from limit line on the positive offset F dB
*1: Absolute power when "Measurement Type" on page 1700 is Total Power Ref or
PSD Ref; Peak power when "Measurement Type" on page 1700 is Spectrum Peak
Ref
3.9.2 Results for n = 2-4
n Data
2 Returns the displayed frequency domain spectrum trace data for Trace 1 separated by commas
3 Returns the displayed frequency domain absolute limit trace data separated by commas
4 Returns the displayed frequency domain relative limit trace data separated by commas
3.9.3 Results for n = 5
Returns comma-separated scalar values of the absolute integrated power when
"Measurement Type" on page 1700 is Total Power Ref or PSD Ref and the absolute
peak power when "Measurement Type" on page 1700 is Spectrum Peak Ref of the
segment frequencies
1530 Spectrum Analyzer Mode User's &Programmer's Reference
