6 Input/Output
6.1 RF Source
Dependencies Not available in E7760B
Preset
DOWN
Range
DOWN | UP
Freq/Chan
Lets you select the frequency or channel value for the current step. If the Band
selection for the current row is NONE, you enter a frequency. Otherwise, enter a
channel, which causes the frequency to be automatically selected, based on the
Band selection.
Entering a Frequency
If the Band selection for the current row is NONE, enter a Frequency. This field in the
table allows you to select the frequency value for the current step.
Remote Command
:SOURce:LIST:STEP[1]|2|…|1000:SETup:CNFRequency <double>
:SOURce:LIST:STEP[1]|2|…|1000:SETup:CNFRequency?
Example
:SOUR:LIST:STEP2:SET:CNFR 1GHz
:SOUR:LIST:STEP2:SET:CNFR?
Notes SCPI is supported after A.09.40
Used to setup channel number or frequency setting, according to the current Radio Band setting. If
Radio Band is NONE, then the value is frequency. If Radio Band is not NONE, then the value is channel
number
Dependencies Not available in E7760B
Couplings The frequency value is coupled to the channel band and number for the step, such that updates to the
radio band and channel number will update the frequency value to the corresponding absolute
frequency. The reverse is also true, changing the frequency value causes the value of the channel
number to be updated
Preset 1.00 GHz
Min 10.00 MHz
Max Hardware Dependent:
Option 503 3.6 GHz
Option 504 3.9 GHz
Option 506 6.00 GHz
Option F06 6.08 GHz
Option F06 & EP6 6.60 GHz
Spectrum Analyzer Mode User's &Programmer's Reference 2247
