6 Input/Output
6.1 RF Source
Min -200.00 dB
Max 200.00 dB
6.1.6.6 Amplitude Increment
Changes the step size for the RF Power function. Once an increment size has been
selected and the RF Amplitude function is active, the step keys (and the UP|DOWN
parameters for RF Power from remote commands) change the RF Power by the set
value. This feature exists in EXG and MXG.
Remote Command
:SOURce:POWer:STEP[:INCRement]
<ampl>
:SOURce:POWer:STEP[:INCRement]?
Example
:SOUR:POW:STEP 1
Notes The Amplitude Increment unit follows the units set in Power Unit
Couplings Coupled to the Step size of the RF Power function
Preset 1 dB
Min 0.1 dB
Max 10 dB
6.1.7 Frequency
Lets you control the frequency of the Source. Same as "Frequency" on page 2261
under "Frequency Setup" on page 2261.
Example
:SOUR:FREQ 1.00 GHz
6.1.8 List Sequencer
Accesses sub-menus for configuring the List Sequencer.
List sequences allow you to enter frequencies and amplitudes at unequal intervals in
nonlinear ascending, descending or random order. Each step within the list can also
include its own waveform file for playback, step duration, trigger event and trigger
output.
The complexities involved in configuring the List Sequencer do not lend themselves
to manual configuration; hence the manual configuration for this feature is limited.
For easier configuration of the List Sequencer, it is recommended that you use either
SCPI, or load a tab-delimited file containing the setup parameters in a tabular form.
The details of the SCPI for configuring the List Sequencer can be found in "Step
Configuration (Remote Command Only)" on page 2252.
2236 Spectrum Analyzer Mode User's &Programmer's Reference
