7 Save/Recall/Print

7.2 Recall

Preset Not part of Preset, but reset to Correction 1 by Restore Input/Output Defaults

Survives a shutdown

7.2.8 Complex Correction

Imports Complex Corrections files in the PC-readable .s2p format.

Complex Correction files contain amplitude and phase correction data in a form that

can be imported into Excel or similar spreadsheets, as well as header data that gives

information on the correction.

The default path for Complex Corrections files is:

My Documents\complexCorrections\

Remote Command

:MMEMory:LOAD:CCORrection <integer>, <filename>

Example Recall the Complex Correction data from the file mycor.s2p in the current directory to the 2nd

Complex Correction table, and turns on Complex Correction 2:

:MMEM:LOAD:CCOR 2, "mycor.s2p"

Dependencies Not supported by all measurements. The tab does not appear at all if no measurements in the Mode

support it

Errors are reported if the file is empty or missing, or if the file type does not match, or if there is a

mismatch between the file type and the destination data type

Couplings When a complex correction file is loaded from mass storage, it is automatically turned ON and Apply

Corrections is set ON. This allows you to see its effect, thus confirming the load

Annotation After recall is complete, an advisory is displayed in the message bar confirming which file was recalled

7.2.8.1 Select Complex Correction

Selects the register into which the recalled Complex Correction will be placed, for

example, Complex Correction 1.

Preset Not part of Preset, but is reset to Correction 1 by Restore Input/Output Defaults

Survives a shutdown

7.2.9 Correction Group

Selects Correction Group as the data type to be imported. The next step is to press

Recall From to open the file dialog. When recalling a correction group, the

correction group settings, range table and correction files data will be loaded.

If there are values defined in the correction group range, and you accessed this

function from the front panel, there will be a message prompt that asks for your

confirmation, because the values will be overwritten during the recall.

Spectrum Analyzer Mode User's &Programmer's Reference 2542
