Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.11 Harmonics Measurement
[:SENSe]:HARMonics:TONE[1]|2|…|10:BANDwidth|BWIDth[:RESolution]:AUTO?
Preset
ON
Dwell Time
Sets the Dwell Time for the specified harmonic. In zero-span, the Auto mode strikes
a balance between measurement speed and accuracy; increasing the dwell time will
reduce measurement speed while increasing accuracy.
Remote
Command
[:SENSe]:HARMonics:TONE[1]|2|…|10:SWEep:TIME <time>
[:SENSe]:HARMonics:TONE[1]|2|…|10:SWEep:TIME?
Example
:HARM:TONE:SWE:TIME 100 us
Set the sweep time for this harmonic to 100 us
Couplings If the Sweep Time is set to Auto, the sweep time will be 200 divided by the resolution bandwidth, to a
minimum of 10 ms
Preset The actual preset value depends upon an input signal, since Dwell Time defaults to Sense
Min 100 us
Max 4000 s
Auto Function
Remote
Command
[:SENSe]:HARMonics:TONE[1]|2|…|10:SWEep:TIME:AUTO OFF | ON | 0 | 1
[:SENSe]:HARMonics:TONE[1]|2|…|10:SWEep:TIME:AUTO?
Preset
ON
Backwards Compatibility Command
Backwards Compatibility
SCPI
[:SENSe]:HARMonics:RANGe[:LIST]:SWEeptime <time>, …
[:SENSe]:HARMonics:RANGe[:LIST]:SWEeptime?
Backwards Compatibility Auto Function
Preset
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON
Auto-Fill
Sets up the "Range Table" on page 1912, based on the first entry in the range table.
When selected, each of the entries after range 1 are set appropriately.
Remote
Command
[:SENSe]:HARMonics:RTABle:FILL
Example
:HARM:RTAB:FILL
fills the range table based on current fundamental measurement settings
1914 Spectrum Analyzer Mode User's &Programmer's Reference
