Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.4 Occupied BW Measurement
3.4.5.1 Meas Display
Contains controls for setting the display for the current Measurement, View or
Window.
x dB BW Boundaries On/Off
Turns the x dB BW Boundaries On or Off.
Remote Command
:DISPlay:OBWidth:WINDow[1]:XDB 0 | 1 | OFF | ON
:DISPlay:OBWidth:WINDow[1]:XDB?
Example
:DISP:OBW:WIND:XDB 1
:DISP:OBW:WIND:XDB?
Preset 0
State Saved Saved in instrument state
Range
OFF|ON
Backwards Compatibility
SCPI
:DISPlay:OBWidth:VIEW:WINDow[1]:XDB
Boundary Frequency
Selects frequency display type:
–
OFFSet: offsets from Center Freq to OBW boundary frequency are displayed
–
ABSolute: absolute frequencies are displayed
Remote
Command
:DISPlay:OBWidth:WINDow2:BOUNdaries:FREQuency OFFSet | ABSolute
:DISPlay:OBWidth:WINDow2:BOUNdaries:FREQuency?
Example
:DISP:OBW:WIND2:BOUN:FREQ ABS
:DISP:OBW:WIND2:BOUN:FREQ?
Preset
OFFSet
State Saved Saved in instrument state
Range
OFFSet|ABSolute
Backwards
Compatibility
SCPI
:DISPlay:OBWidth:VIEW2:WINDow2:BOUNdaries:FREQuency
774 Spectrum Analyzer Mode User's &Programmer's Reference
