3 Spectrum Analyzer Mode
3.10 TOI Measurement
State Saved Saved in instrument state
Min Variable. Limited to values that keep the reference level within the range –327.6dB to 327.6dB
Max 327.6 dB
Annotation The offset is displayed as “Ref Offset <value>” to the right of the reference level annotation if nonzero.
When the offset is zero, no annotation is shown
Auto Function
Remote
Command
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEVel:OFFSet:STATe OFF | ON | 0 | 1
:DISPlay:WINDow[1]:TRACe:Y[:SCALe]:RLEVel:OFFSet:STATe?
Example
:DISP:WIND:TRAC:Y:RLEV:OFFS:STAT ON
Turns Ref Level Offset On
Preset
OFF
Ref Position
Positions the reference level at the top, center, or bottom of the Y Scale display.
Changing the reference position does not change the reference level value.
Remote
Command
:DISPlay:TOI:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RPOSition TOP | CENTer |
BOTTom
:DISPlay:TOI:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:RPOSition?
Example
:DISP:TOI:VIEW:WIND:TRAC:Y:RPOS BOTT
:DISP:TOI:VIEW:WIND:TRAC:Y:RPOS?
Preset
TOP
State Saved Saved in instrument state
Range
TOP|CENTer|BOTTom
Annotation The greater than (>) and less than (<) symbols are displayed on both sides of the graph to indicate the
Ref Position
3.10.3.2 Attenuation
Controls the attenuator functions and interactions between the attenuation system
components.
There are two attenuator configurations in the X-Series. One is a Dual-Attenuator
configuration consisting of a mechanical attenuator and an optional electronic
attenuator. The other configuration uses a single attenuator with combined
mechanical and electronic sections that controls all the attenuation functions.
Different models in the X-Series come with different configurations.
Spectrum Analyzer Mode User's &Programmer's Reference 1767
